17-21/T1D-CP2R1TY/4T
$0.08
Tax excluded
17-21/T1D-CP2R1TY/4T
- Color
- White
- Lens Color
- Yellow Diffused
- Luminous Intensity
- 57mcd
- Forward Current
- 5mA
- Forward Voltage
- 2.6V
- Maximum Voltage
- 3.0V
- Pulsed Forward Current
- 100mA
- Beam Angle
- 150°
- Mounting
- SMD
- Operating Temperature
- -40°C to 85°C
- Storage Temperature
- -40°C to 90°C
- Emission Direction
- TopView
- Thickness
- 1mm
