EADCS056RA3
$0.57
Tax excluded
Description
This part is a 14.22mm (0.56”) digit height seven-segment display. The display provides excellent reliability in bright ambient light. The device is made with red segments and black surface.
Features
- Industrial standard size. Low power consumption. Categorized for luminous intensity. Pb free and RoHS compliant.
Applications
- Home Appliances Instrument Panels Digital Readout Displays
EADCS056RA3
75 Items
- Forward Current
- 10mA
- Package
- Rectangle
- Mounting
- Through Hole
- Thickness
- 8mm
- Forward Voltage
- 2.4V
- Pulsed Forward Current
- 60mA
- Operating Temperature
- -40°C to 85°C
- Storage Temperature
- -40°C to 100°C
- Peak Wavelength
- 639nm
- Number of Pins
- 10Pins
