PT204-6B
$0.20
Tax excluded
Description
This part is a high speed and high sensitive NPN silicon phototransistor molded in a standard φ3 mm package. Due to its black epoxy the device is sensitive.
Features
- Fast response time High photo sensitivity Pb free The product itself will remain within RoHS compliant version.
Applications
- Infrared Applied System Camera Printer Optoelectronic Switch
PT204-6B
- Lens Color
- Black
- Package
- 3mm Round Lamp
- Mounting
- Through Hole
- Operating Temperature
- -25°C to 85°C
- Storage Temperature
- -40°C to 85°C
- Rise/Fall Time
- 15000 / 15000 ns
- Saturation Voltage
- 0.4V
