ELD3H7(TA)-V

$0.65
Tax excluded

Description

The ELD3H7-G contains of an infrared emitting diode optically coupled to a phototransistor detector encapsulated with green compound. ELD3H7 offers 2 channels in a 8-pin small outline SMD package.

Features

  • Halogens free.(Br <900 ppm ;Cl <900 ppm ; Br+Cl < 1500 ppm)
  • Current transfer ratios offered in narrow ranges
  • EL205: 40-80% EL211: >20%
  • EL206: 63-125% EL212: >50%
  • EL207: 100-200% EL213: >100%
  • EL208: 160-320%
  • High isolation voltage between input and output (Viso = 3750 Vrms)
  • Operating temperature range of -55 to +110℃
  • High BVceo of 80V
  • Standard SO-8 footprint package
  • Compliance with EU REACH
  • Pb free and RoHS compliant
  • UL and cUL approved(No. E214129)
  • VDE approval (pending)
  • SEMKO approved
  • NEMKO approved
  • DEMKO approved...
ELD3H7(TA)-V
Forward Current
20mA
Maximum Voltage
1.4V
Package
8 Pin SSOP
Mounting
SMD
Operating Temperature
-55°C to 110°C
Storage Temperature
-55°C to 125°C
Isolation Voltage
3750Vrms
CTR (Current Transfer Ratio)
600
Number of Pins
Quad
