ITR9608-F

$1.50
Tax excluded

Description

The ITR9608-F consist of an infrared emitting diode and an silicon phototransistor, encased side-by-side on converging optical axis in a black thermoplastic housing, The phototransistor receives radiation from the IR LED only .This is the normal situation. But when an object is in between, phototransistor could not receives the radiation. For additional component information , please refer to IR928-6C-F and PT928-6C-F.

Features

  • Fast response time High analytic High sensitivity Cut-off visible wavelength λP=940nm Pb Free This product itself will remain within RoHS compliant version.

Applications

  • Mouse Copier Switch Scanner Floppy Disk Driver Non-Contact Switching For Direct Board
ITR9608-F
Forward Current
20mA
Forward Voltage
1.5V
Maximum Voltage
1.5V
Package
Through-Hole Module
Mounting
Through Hole
Operating Temperature
-25°C to 85°C
Storage Temperature
-40°C to 85°C
Peak Wavelength
940nm
