ITR8105

$1.50
Tax excluded

Description

The ITR8105 consist of an infrared emitting diode and an NPN silicon phototransistor, encased side-by-side on converging optical axis in a black thermoplastic housing The phototransistor receives radiation from the IR LED only .This is the normal situation. But when an object is in between, phototransistor could not receives the radiation. For additional component information , please refer to IR928-6C and PT928-6C.

Features

  • Fast response time
  • High sensitivity
  • Cut-off visible wavelength λp=940nm
  • Pb free
  • This product itself will remain within RoHS compliant version
  • Compliance with EU REACH
  • Compliance Halogen Free (Br < 900ppm, Cl < 900ppm, Br+Cl < 1500ppm)

Applications

  • Mouse Copier
  • Switch Scanner
  • Floppy Disk Driver
  • Non-...
ITR8105
Forward Current
20mA
Maximum Voltage
1.6V
Package
Through-Hole Module
Peak Wavelength
940nm
