ITR9813

$1.50
Tax excluded

Description

The ITR9813 consist of an infrared emitting diode and an NPN silicon phototransistor, encased side-by-side on converging optical axis in a black thermoplastic housing The packaging system is designed to optimize the mechanical resolution, Coupling effiency and insulates ambient light. For additional component information , please refer to IR908-7C/F56 and PDT908-7C/56.

Features

  • Fast response time High analytic High sensitivity Cut-off visible wavelength λP=940nm Pb Free This product itself will remain within RoHS compliant version.

Applications

  • Mouse Copier Switch Scanner Floppy Disk Driver Non-Contact Switching For Direct Board
ITR9813
Forward Current
20mA
Forward Voltage
1.5V
Maximum Voltage
1.5V
Package
Through-Hole Module
Mounting
Through Hole
Operating Temperature
-25°C to 85°C
Storage Temperature
-40°C to 100°C
Peak Wavelength
940nm
