IR67-21C/L261/S65/TR8

$1.50
Tax excluded

Description

IR67-21C/L261/S65/TR8 is an infrared emitting diode in miniature SMD package which is molded in a water clear plastic with flat top view lens. The device is spectrally matched with silicon photodiode and phototransistor.

Features

  • Compatible with infrared and vapor phase reflow solder process.
  • Low forward voltage.
  • View angle 120°
  • Pb free
  • The product itself will remain within RoHS compliant version.
  • Compliance with EU REACH.
  • Compliance Halogen Free .(Br <900 ppm ,Cl <900 ppm , Br+Cl < 1500 ppm)

Applications

  • Sensor
  • Optoelectronic Switch
  • Camera
  • Vcr
  • Video
  • Smoke Detector
IR67-21C/L261/S65/TR8
Forward Current
20mA
Maximum Voltage
1.6V
Beam Angle
120°
Package
3528
Peak Wavelength
940nm
Radiant Intensity
1 mW/sr
