SIR17-21C/TR8
$0.45
Tax excluded
Description
This is an infrared emitting diode in miniature SMD package which is molded in a water clear plastic with flat top view lens. The device is spectrally matched with silicon photodiode and phototransistor.
Features
- Small double-end package Low forward voltage Good spectral matching to Si photo detector Package in 8mm tape on 7” diameter reel Pb free RoHS Compliance
Applications
- Pcb Mounted Infrared Sensor Infrared Emitting For Miniature Light Barrier Floppy Disk Drive Optoelectronic Switch Smoke Detector
SIR17-21C/TR8
- Lens Color
- Water Clear
- Forward Current
- 20mA
- Forward Voltage
- 1.3V
- Maximum Voltage
- 1.6V
- Beam Angle
- 150°
- Package
- 805
- Mounting
- SMD
- Operating Temperature
- -40°C to 85°C
- Storage Temperature
- -40°C to 100°C
- Thickness
- 1mm
- Peak Wavelength
- 875nm
- Radiant Intensity
- 0.2 mW/sr
