57-11-GHC-R1U2V1A7E-BT8-AM

$0.50
Tax excluded

Features

  • P-LCC-4 package.
  • Colorless clear resin.
  • Wide viewing angle 120 o.
  • Inner reflector and white package.
  • Brightness: 560 to 900mcd at 20mA
  • Precondition: Bases on JEDEC J-STD 020D Level 2
  • Qualification according to AEC-Q101 rev C.
  • Automotive reflow profile (IR reflow or wave soldering)

Applications

  • Automotive Backlighting Or Indicator: Dashboard, Switch, Audio And Video Equipments…Etc.
  • Backlight: Lcd, Switches, Symbol, Mobile Phone And Illuminated Advertising.
  • Display For Indoor And Outdoor Application.
  • Ideal For Coupling Into Light Guides.
  • Substitution Of Traditional Light.
  • Optical Indicator.
57-11-GHC-R1U2V1A7E-BT8-AM
Color
Green
Green; Luminous Intensity
Luminous Intensity
560mcd
Forward Current
20mA
Maximum Voltage
3.8V
Beam Angle
120°
Package
4040
