Part Number: EALP02RRAAA0
Amber
Thru-Hole LED, Rectangular, 0205, Orange
Description:
The series is specially designed for applications requiring higher brightness
The led lamps are available with different colors, intensities.
Features:
Choice of various viewing angles
Available on tape and reel.
Reliable and robust
The product itself will remain within RoHS compliant version.
Compliance with EU REACH
Compliance Halogen free. (Br <900 ppm, Cl<900 ppm, Br+Cl <1500 ppm).
Applications:
TV set
Monitor
Telephone
Computer
| Peak Wavelength | 611nm |
| Packaging | Bag |
| Package | Rectangle |
| Off State Lens Color | Orange Trans |
| Test Current | 20mA |
| Mounting | Through Hole |
| Min. Storage Temp. | -40C |
| Min. Operating Temp. | -40C |
| Min. Forward Voltage | 1.7V |
| Typ. Forward Voltage | 2V |
| Width | 2mm |
| Viewing Angle | 40 deg |
| Type | Rectangle 2x5 |
| Min. Flux | 40mcd |
| Typ. Flux | 80mcd |
| Typ. Dominant Wavelength | 605nm |
| Height | 7mm |
| Max. Forward current | 25mA |
| Length | 5mm |
| Max. Forward Voltage | 2.4V |
| Max. Storage Temp. | 100C |
| Max. Pulsed Current | 60mA |
| Max. Operating Temp. | 85C |
