Part Number: CSP0504AN1F1-WP36382803005-T(EU)

Description
The 0504 CSP LED is much smaller than general components, thus enable smaller board size, higher packing density,
reduced storage space and finally smaller equipment to be obtained.

Features

• Dimension: 0.55*0.45*0.15 mm LED
  Direct attach-Flip Chip type.
  Wide viewing angle.
  Suitable for vapor-phase reflow, Infrared reflow and wave solder processes.
  Computable with automatic placement equipment.
  Pb-free.
  The product itself will remain within RoHS compliant version.
  Compliance with EU REACH.
  Compliance Halogen Free. (Br<900ppm,CI<900ppm,Br+CI<1500ppm)
  Precondition: Bases on JEDEC J-STD 020D Level 3

Applications
Status indicator, keypad, keyboard, and industrial equipment.

Light pipe application

General Use
